Взрывозащищенный серводвигатель EXP130 IICT4 мощностью 2 кВт, 2,6 кВт, 3,8 кВт

EXP130 explosion-proof servomotor

The EXP130 explosion-proof AC permanent magnet synchronous servo motor is a drive motor specifically designed for use in Zone 1 and 2 and combustible dust environments where IIA, IIB, IIC, T1-T4 explosive atmospheres exist.

Brand: Ipsen EXPSION
Voltage range: 48~380VAC
Power range: 2kW, 2.6kW, 3.8kW
Explosion protection level: EX d IIC T4
Protection level: IP65

Product Parameters

Product model	Rated power	Nominal torque	Nominal speed	Rated current	Peak torque	Peak rotation	Peak current
	(w)	(Nm)	(rpm)	(Arms)	(Nm)	(rpm)	(Arms)
48VDCVoltage
EXP13020S	2000	7.7	2500	52	15.4	2800	104
EXP13026S	2600	10	2500	76	20	2800	152
EXP13026S	3800	15	2500	81	22.5	2650	122
72VDCVoltage
EXP13020Q	2000	7.7	2500	28	15.4	3000	56
EXP13026Q	2600	10	2500	38	20	2800	76
EXP13026Q	3800	15	2500	52	30	2800	104
220VACVoltage
EXP13020L	2000	7.7	2500	7.5	22	2800	15.3
EXP13026L	2600	10	2500	10	25	3000	19.4
EXP13038L	3800	15	2500	13.5	30	3000	27.7
380VACVoltage
EXP13020H	2000	2.39	3000	1.6	7.1	4000	4.8
EXP13026H	2600	3.5	3000	3	10.5	4500	9
EXP13038H	3800	15	2500	7.4	30	3000	14.8
