Взрывозащищенный серводвигатель EXP90IICT4 мощность 750 Вт, 1000 Вт

EXP90 explosion-proof servomotor

The EXP90 explosion-proof AC permanent magnet synchronous servo motor is a drive motor specifically designed for use in Zone 1 and 2 and combustible dust environments where IIA, IIB, IIC, T1-T4 explosive atmospheres exist.

Brand: Ipsen EXPSION
Voltage Range: 48~380VAC
Power Range: 750W, 1000W
Explosion Protection Level: EX d IIC T4
Protection Level: IP65

Product Parameters

Product model	Rated power	Nominal torque	Nominal speed	Rated current	Peak torque	Peak rotation	Peak current
	(w)	(Nm)	(rpm)	(Arms)	(Nm)	(rpm)	(Arms)
48VDC voltage
EXP9008S	750	2.39	3000	19.5	4.78	4000	39
EXP9010S	1000	3.5	3000	26	7	4000	52
72VDC voltage
EXP9008Q	750	2.39	3000	10.5	4.78	3500	21
EXP9010Q	1000	3.5	3000	16	7	3500	32
220VAC voltage
EXP9008L	750	2.39	3000	3	7.1	3500	9
EXP9010L	1000	3.5	3000	4.5	10.5	3500	13.5
380VACнапряжение
EXP9008H	750	2.39	3000	1.6	7.1	4000	4.8
EXP9010H	1000	3.5	3000	3	10.5	4500	9
